Model | casting | Inlet diameter | Exhaust diameter | Compression standard | Bhp standard |
1300 America, 1275 Spridget,mini 1275 GT and standard Metro | 1 5/16″ 33,33mm |
1 5/32″ 29,53mm |
8.8:1 (GT) | 56 (GT) | |
‘S’ units, MG metro, 1300 GT,’90’s Cooper and Sprite Tbi | 1.4″ (TBASE page 161 (2nd edition)) 35.56 mm |
1 5/32″ 29,53mm |
19-2-2002- from the yahoo.list: “Dear all FB has probably seen this already,but it appears the Maestro/Montego 1275 models used the MG Metro big valve 12G940 cylinder head and cam to produce 69bhp. According to Haynes they started off with 1.312″ inlets and 1.156″ exhaust valves.But from engine No.12H999104761 and 804102434 they had 1.4″ inlets.Which is worth about 5bhp.Get down that scrapyard! IAN Nicholls” |
||
MG Metro Turbo | 1 5/16″ 33,33mm |
1 5/32″ 29,53mm sodium cooled |
9.4:1 | 94 | |
1.3i minis with cats 1991 on | 9.4:1 | ||||
1991on injection minis | 10:1 | 54 63 for Cooper |
|||
1990-92 non injection coopers | 10:1 | ||||
1000s with cats 1989 on | 9.6:1 | ||||
1000s 83-89 | 10.6:1 | ||||
CooperS mkIII | 9.75:1 | ||||
Different heads to the A-series engine
compiled by Jerker Johansson,Sweden 1987 |
From the book: The Sporting Minis | by: John Brigden | ISBN: 0-947981-40-3 | ||
Number of Casting | Inlet | Exhaust | Volume | Normally fitted to | Fits also |
2A629 2A628 12A1456 |
1 1/16″ 26.98mm |
1″ 25.4mm |
24,6cc | 850 Mini, A35,A40,Minor, SpriteMkI | 998,1100 and Cooper |
12A1458 | 1 1/16″ 26.98mm |
1″ 25.4mm |
24,6cc | late 850 &998 | as above but a hole in the front for temp gauge |
12G185 (and/or marked as 12A185 * -see bottom of page- ) | 1 1/16″ 26.98mm |
1″ 25.4mm |
24,6cc | 997 Cooper | fits as bigvalvehead for 850 & 998 |
12G202 | 1 5/32″ 29,53mm |
1″ 25.4mm |
26,1cc | Austin/Morris 1100 and/or 997 Cooper * -see bottom of page- |
As above but square formed inlets |
12G206 | 1 7/32″ 30.95mm |
1″ 25.4mm |
28,3cc | Early MG 1100 | upgraded 12G202 |
12G295 | 1 7/32″ 30.95mm |
1″ 25.4mm |
28,3cc | 998 Cooper MG 1100 Sprite MKIII |
Fits on 998 when bigger valves are needed |
12G940 9 Bolts |
1 5/16″ 33,33mm |
1 5/32″ 29,53mm |
21,4cc | 1275GT,A/M1300 Sprite MK IV Marina 1,3 |
Can be modified to the specifications below |
12G940 11 Bolts |
1 13/32″ 35,6mm |
1 5/32″ 29,53mm |
21,4cc | Austin 1300 GT MG 1300 MK II late Cooper S |
Fits on 1275 Gt when bigger valves are needed |
12A185 AEG165 AEG163 |
1 13/32″ 35,6mm |
1 7/32″ 30.95mm |
21,4cc | Cooper S | Can be used instead of the 11 bolted 12G940 |
12G940 | 1 5/16″ 33,33mm |
1 5/32″ 29,53mm |
21,4cc | Turbo MG | |
12G1316 | 1 5/16″ 33,33mm |
1 5/32″ 29,53mm |
21,4cc ?? | 1275 Austin America | The 12G1316 is the Austin America smog head. It’s a really beefy head and Vizard liked itbecause it had plenty of room for modification. There isn’t a lot of information on modding
these heads, I suspect, because they were not generally available in the UK. It’s quite probable that Vizard knew of them through APT. They are a good solid head, same valve size as the standard (non-MG) 12G940. I think they are a good choice. Cheers, Kelley |
CAM4180 | 1.0625″ 26.9875 mm |
1″ 25.4mm |
25.5cc | 998 Mini A+ and lead free |
Last modified: 22 September 1996, with facts from Frans Marx |
—–Enginetype—– | ——Stroke—– | —–Bore—– | —–CC`s—– | ||
1000cc | 76,2mm | 64.57
65.08 65.33 65.58 66.1 68 |
998
1013 1021 1029 1045 1106 |
||
1100cc | 83,75mm | 64,57
65,08 65,33 65,58 66,1 68 68,5 68,76 69,01 69,52 |
1098
1113 1122 1131 1149 1216 1234 1243 1252 1271 |
||
1300cc | 81,28mm | 70,61
71,12 71,37 71,62 72,12 73,5 73,65 74 74,15 74,40 |
1272
1290 1300 1309 1328 1379 1385 1398 1403 1412 |
||
1300cc Shortstroke | 76mm | 73,5
74 |
1289
1306 |
||
1300cc Longstroke | 84mm | 70,61
71,62 72,12 73,5 74 74,7 |
1316
1353 1372 1425 1444 1472 |
||
1300cc Longstroke | 86mm | 73,5
74 74,7 |
1459
1479 1506 |
||
1300cc Longstroke | 91mm | 73,5
74 74,4 74,7 |
1544
1565 1582 1594 |
||
850cc | 68,25mm | 62,94 | 848 | ||
Engine ———– | Casting — | Chamber volume —- | |||
850
948 |
2A628
12A1456 2A629 |
24,5cc | |||
997
1098 |
12G202 | 26,1cc | |||
998
1098 1100 |
12G206
12G295 |
28,3cc | |||
1275
1300 |
12G940
12A185 AFG163 |
21,4cc | |||
Performance figures per type: According to ’the sporting minis’ p. 119 | Horse Power | Max Speed (Mph) | 0-60 time | Mpg | source |
Mini Cooper 997 | 55 | 85 | 17.2 | 34.6 | The Motor 20/9/1961 |
Mini Cooper 998 | 55 | 90 | 14.8 | 31.5 | The Motor 6/11/1965 |
Mini Cooper S 1071 | 70 | 95 | 12.9 | 26.8 | The Motor 24/4/1963 |
Mini Cooper S 970 | 65 | 92 | n/a | n/a | |
Mini Cooper S 1275 | 76 | 97 | 10.9 | 29.9 | The Motor 5/9/1964 |
Mini 1275 GT | 59 | 90 | 13.3 | 30.5 | Autocar 6/9/1971 |
Cooper S Touring 1.3i | 85 | 95 | 9.95 | 38.6 | |
Cooper S Sport | 85 | 97 | 9.65 | 36.5 | |
Cooper conversion 998 | 64 | 88 | 13.2 | 29.6 | Autocar & Motor 14/6/1989 |
Mini Mayfair | 41 | 78 | 22 | 38.0 | Autocar & Motor 23/8/1989 |
Mini “Hot Rod” | 160 | ||||
Mini Van 850 | 34 | 71 | 28.3 | 41.6 | Mini Gold Portfolio ’59-’69 (p. 91-93) |
Mini Clubman Wagon 1100 | 48 | 130 km/h | 19.4 (0-100 km/h) | 8.3 l/100km | Mini Gold Portfolio ’69-’80 |
Date sent: Tue, 28 Sep 1999 07:40:13 -0700 (PDT)
From: Kelley Mascher <mascher@u.washington.edu>
To: Theo van den Bogaard <T.A.J.M.vdnBogaard@uvt.nl>
Subject: Re: BOUNCE Casting “MOWOG 12A185” on a cylinder head
Please feel free to use anything I write on
the list. Also please use any retraction I
may have to write later. ;^)
You have the most complete list I’ve seen for
heads and casting numbers. If you like I’ll
send you numbers for the North American
smog heads these were mostly from Canada.
I did notice a couple of anomalies in the list.
There is a typo, AEG163 is listed as AFG163.
Also there doesn’t seem to be a listing for
the 997 Cooper head. In my book it’s listed
as a 12G202.
Cheers and thanks for the website,
Kelley Mascher (206) 528-2713
Children’s Hospital & Med. Center mascher@u.washington.edu
Audiology Research Seattle, Washington USA
On Tue, 28 Sep 1999, Theo van den Bogaard wrote:
> Date: Tue, 28 Sep 1999 09:03:40 MET
> From: Theo van den Bogaard <T.A.J.M.vdnBogaard@uvt.nl>
> To: Kelley Mascher <mascher@u.washington.edu>
> Subject: Re: BOUNCE Casting “MOWOG 12A185” on a cylinder head
>
> Hi Kelly,
>
> thanks for the clarification, may I use this mail to quote from in my table ??
>
> TIA,
> Theo van den Bogaard
>
>
> Date sent: Mon, 27 Sep 1999 09:10:17 -0700 (PDT)
> From: Kelley Mascher <mascher@u.washington.edu>
> To: Theo van den Bogaard <T.A.J.M.vdnBogaard@uvt.nl>
> Copies to: mini-list@autox.team.net
> Subject: Re: BOUNCE Casting “MOWOG 12A185” on a cylinder head
>
> >
> > Just before I wrote my last message on this
> > subject I went out to the garage. Sure enough,
> > the head said 12A185 in the casting and it has
> > the beak in the chamber like a small bore head.
> >
> > I recall measuring the valves when I first noticed
> > the casting number about a year ago. I though I
> > had myself a real Cooper ‘S’ head. Small valves,
> > the same as a 12G295. I wasn’t too disappointed
> > after all it was on an 850.
> >
> > Until someone on the list tells me that they have
> > a 12A185 head with AEG163 valves in it, I’ll assume
> > that the books are inaccurate on this point.
> >
> > Photos upon request…
> >
> > Kelley Mascher (206) 528-2713
> > Children’s Hospital & Med. Center mascher@u.washington.edu
> > Audiology Research Seattle, Washington USA
> >
> > On Mon, 27 Sep 1999, Theo van den Bogaard wrote:
> >
> > > Date: Mon, 27 Sep 1999 13:16:00 MET
> > > From: Theo van den Bogaard <T.A.J.M.vdnBogaard@uvt.nl>
> > > To: mini-list@autox.team.net
> > > Subject: Re: BOUNCE Casting “MOWOG 12A185” on a cylinder head
> > >
> > > Date sent: Sun, 26 Sep 1999 15:39:30 -0700 (PDT)
> > > From: Kelley Mascher <mascher@u.washington.edu>
> > > To: krausefamily <krausefamily@uswest.net>
> > > Copies to: mini-list@autox.team.net
> > > Subject: Re: BOUNCE Casting “MOWOG 12A185” on a cylinder head
> > >
> > > >
> > > > I have seen the 12A185 head listed as a MkI
> > > > Cooper ‘S’ head.
> > > >
> > > > On the other hand I own a 12A185 head that
> > > > is a bog standard small bore head. It came
> > > > on a MkII 850 I bought for parts. I would
> > > > guess that it originating on an 1100 is
> > > > a definite possibility.
> > > >
> > > > Cheers,
> > > >
> > > > Kelley Mascher (206) 528-2713
> > > > Children’s Hospital & Med. Center mascher@u.washington.edu
> > > > Audiology Research Seattle, Washington USA
> > >
> > > http://cwis.uvt.nl/~dbi/users/theo/heads.htm
> > > lists the 12A185 as Cooper S
> > > and the 12G185 as small-bore
> > >
> > > .. perhaps the MOWOG got his lettes mixed up an a ‘bad’ day ??
> > > measure the valves and compare to the table …
> > >
> > > >
> > > > On Sat, 25 Sep 1999, list adMINIstrator wrote:
> > > >
> > > > > Date: Sat, 25 Sep 1999 22:05:44 -0600
> > > > > From: list adMINIstrator <chichm@planet.eon.net>
> > > > > To: mini-list@autox.team.net
> > > > > Subject: BOUNCE Casting “MOWOG 12A185” on a cylinder head
> > > > >
> > > > > BOUNCE Non-member submission from [krausefamily <krausefamily@uswest.net>]
> > > > >
> > > > > Date: Wed, 15 Sep 1999 20:56:07 -0600
> > > > > From: krausefamily <krausefamily@uswest.net>
> > > > > Subject: Casting “MOWOG 12A185” on a cylinder head
> > > > >
> > > > > Does casting number “MOWOG 12A185” on a cylinder head give
> > > > > some indication as to the origins and application for the
> > > > > particular head? One theory I’ve heard is that this is a
> > > > > head from an 1100cc Morris? The other theory is that this
> > > > > is either a 1275cc head or will otherwise function with a
> > > > > 1275cc Sprite/Midget. Can you shed any light on this?
> > > > >
> > > > > John Krause
> > > > > krausefamily@uswest.net
> > > > >
> > > > > *********************************************************
> > > > > OK, so I’m busy getting on with my life, OK?
> > >
> > > HTH,
> > >
> > >
> > > Theo van den Bogaard
> > > Mini Cooper 1.3i BRG + ’71 Red Van
> > > 998cc Appreciation Society
> > > Mail: T.A.J.M.vdnBogaard@uvt.nl
> > >
> > >
